1Selective area on which to create pattern

2Number of objects row and column wise

function rectangularDistribution(cornerPointArray, numDivisionArray) {
    distributionPointArray = [];
    for (var i = 0; i < numDivisionArray[0]; i++) {
        for (var j = 0; j < numDivisionArray[1]; j++) {
            var point = cornerPointArray[0].clone();
            var param1 = i / numDivisionArray[0];
            var param2 = j / numDivisionArray[1];
            point.x = cornerPointArray[0].x * (1 - param1) + cornerPointArray[1].x * param1;
            point.z = cornerPointArray[0].z * (1 - param2) + cornerPointArray[1].z * param2;

            distributionPointArray.push(point);
        }
    }
    return distributionPointArray;
}

function radialDistribution(circlePoints, angularDivisions, radialDivisions) {
    distributionPointArray = [circlePoints[0]];
    var deltaTheta = 2 * Math.PI / angularDivisions;

    for (var i = 0; i < angularDivisions; i++) {
        var rotMatrix = new THREE.Matrix4().makeRotationY(i * deltaTheta);
        for (var j = 1; j < radialDivisions; j++) {
            var param = j / radialDivisions;
            var startPt = circlePoints[0].clone();
            var point = startPt.lerp(circlePoints[1], param).sub(circlePoints[0]);
            point.applyMatrix4(rotMatrix);
            point.add(circlePoints[0]);
            distributionPointArray.push(point);
        }
    }
    return distributionPointArray;
}

function createPattern(viewer, model, patternType, direction, numObjects, distBetweenObjects) {
    var transMat = viewer.impl.getRenderProxy(model, 0).matrixWorld;
    var newTransMat = transMat.clone();
    var modelURN = model.getData().urn;

    viewer2.LoadModel(modelURN).then(function (modelCopy) {
        customGeometries.push(modelCopy);
        const fragCount = model.getFragmentList().fragments.fragId2dbId.length;

        //fragIds range from 0 to fragCount-1
        for (var fragId = 0; fragId < fragCount; ++fragId) {

            var fragProxy = SHub.Globals.viewer.impl.getFragmentProxy(modelCopy, fragId);
            var transformMat = viewer.impl.getRenderProxy(model, fragId).matrixWorld;

            fragProxy.getAnimTransform();
            var position = new THREE.Vector3();
            var quaternion = new THREE.Quaternion();
            var scale = new THREE.Vector3();

            transformMat.decompose(position, quaternion, scale);

            fragProxy.position = position;
            fragProxy.scale = scale;
            fragProxy.quaternion = quaternion;

            fragProxy.updateAnimTransform();
        }

        SHub.Globals.viewer.impl.sceneUpdated(true);

        var bbox = modelCopy.getBoundingBox();
        var translatePt = new THREE.Vector3(bbox.size().x, 0, 0);

        var transformManager = new SHub.Core.TransformManager();
        transformManager.TranslateModel(modelCopy, translatePt);
        viewer.impl.sceneUpdated(true);

    }).catch(function (err) {
        console.log(err);
    });
}
